LD28/SP28 8 Pins In-line Cable Connector IP68 Waterproof

LD28/SP28 Docking Connectors Design and Specifications

LD28/SP28 8-Pin Docking Connector: Modular IP68 Waterproof Connection

The LD28/SP28 8-pin docking connector provides a high-integrity, modular connection solution for industrial systems requiring reliable multi-channel transmission. Its robust docking structure supports both power and signal integration, enabling fast module-level connection and replacement while maintaining consistent electrical performance and IP68 environmental protection.

This docking-type design is optimized for modular assembly systems, allowing equipment to be quickly connected or replaced without compromising sealing or electrical stability.

Key Selection Criteria for the LD28/SP28 Connector

Evaluate these factors to confirm the LD28/SP28 fits your application:

• Multi-Channel Integration: The 8-pin configuration supports simultaneous transmission of multiple signals and/or power lines, suitable for medium-to-high complexity systems.
• Modular Docking Structure: Enables precise alignment and stable mating, ideal for plug-in system architectures and equipment requiring frequent maintenance or replacement.
• Environmental Protection: IP68-rated sealing ensures reliable operation in outdoor, humid, and dust-intensive environments.
• Mechanical Durability: Engineered to withstand repeated docking cycles while maintaining consistent electrical contact performance.
• Maintenance Efficiency: Allows fast module replacement, significantly reducing downtime in industrial and field applications.

Manufacturing and Quality Assurance

Each LD28/SP28 connector is produced through an integrated manufacturing process to ensure consistent quality.

• Integrated Production System: Our factory covers mold development, die-casting, CNC machining, injection molding, cable processing, and final assembly, ensuring stable quality control from start to finish.
• Testing Standards: Each connector is tested for waterproof performance, electrical stability, mechanical endurance, and dimensional accuracy before shipment.
• Customization Capability: OEM and ODM options include pin configuration, cable length, material selection, and system-level integration solutions.

Suitable Applications for the LD28/SP28

This docking connector is well-suited for systems that benefit from modular connection and reliable sealing:

• Modular industrial equipment
• Automation control systems
• Outdoor power and communication systems
• Smart devices and monitoring systems
• Energy and electrical integration systems
• Equipment requiring frequent maintenance or replacement

Application Boundaries

While the LD28/SP28 is designed for demanding environments, consider these limitations:

• Not for high-vibration applications where a threaded or locking coupling may be required instead of a docking connection.
• Not a substitute for a fully potted or overmolded cable assembly in applications requiring permanent, strain-relieved cable exits.
• Confirm pin assignment and current rating against your specific load requirements before integration.

Information to Include with Your Inquiry

To receive an accurate quotation and technical recommendation, please provide:

• Mating connector requirement (plug, socket, or both)
• Pinout or wiring diagram
• Cable outside diameter and conductor size
• Electrical load (current and voltage per pin)
• Operating environment (temperature, humidity, chemical exposure)
• Required order quantity

For detailed specifications on the LD28/SP28 series, refer to the LD28/SP28 Docking Connectors Design and Specifications. Explore the full range of Waterproof Connectors for other configurations.

Next Step

Contact us today for samples, technical drawings, or a customized quotation for your high-performance waterproof docking solution.
