LD28/SP28 Docking Connector Design Overview

The drawing outlines the LD28/SP28 docking connector’s design, highlighting its dimensions, specifications, and choice of materials. This page serves as a reference for engineers and procurement teams evaluating the LD28/SP28 series for panel-to-cable or docking applications, helping you confirm envelope size, material compatibility, and key mechanical parameters before prototyping.

What the Drawing Covers

This dimensional drawing provides the verified outline of the LD28/SP28 docking connector, including:

• Overall envelope dimensions for panel cutout and mating clearance planning
• Mounting hole pattern and flange details for panel installation
• Specified materials used in the housing and contact components
• Key mechanical references needed for integration into your equipment layout

How to Use This Drawing in Your Selection

Use the dimensional data to check whether the LD28/SP28 fits your existing panel opening and whether the connector’s mating depth suits your docking mechanism. Confirm the material choices against your environmental requirements, such as exposure to moisture, chemicals, or temperature cycling. If your application requires a specific cable entry angle or a different mounting style, verify those options against the series datasheet before ordering.

For related dimensional data, see the LD28/SP28 square flange connector dimensions and materials or the LD28/SP28 panel mount connector dimensions and materials.

Next Step

If the LD28/SP28 outline matches your design envelope, submit an inquiry with your required pin count, cable diameter, and mounting configuration to confirm availability and lead time.
