SY11 4 Pin IP67 Waterproof Female Connector Molded Ethernet Cable Assembly

The SY11 4 Pin IP67 Waterproof Female Connector Molded Ethernet Cable Assembly is designed for reliable data and power connections in industrial and outdoor environments. Featuring a pre-molded cable structure and secure bayonet locking design, it provides excellent connection stability, easy installation, and long-term durability.

With an IP67 waterproof rating, this connector assembly offers effective protection against dust, water, and harsh operating conditions. The integrated molding process enhances the cable's mechanical strength, reducing the risk of cable damage and improving overall reliability during continuous use.

The 4 Pin female connector design ensures a secure interface for equipment connections, while the Ethernet cable configuration supports stable signal transmission for communication and control systems.

Key Selection Considerations

When evaluating this connector assembly for your application, consider the following decision points:

• Mating Interface: Confirm the male counterpart connector series and pin arrangement to ensure proper mating with this female connector.
• Cable Length and Routing: Specify the required cable length and routing path to match your installation layout and avoid unnecessary strain on the assembly.
• Environmental Exposure: Verify that IP67 protection meets your application's dust and water exposure requirements, particularly for outdoor or washdown environments.
• Signal Requirements: Confirm that the Ethernet cable configuration supports your data rate and signal integrity needs for communication or control systems.
• Mechanical Retention: Assess whether the bayonet lock structure provides sufficient vibration resistance for your specific mounting conditions.

Application Suitability

This molded cable assembly is well suited for industrial automation equipment, outdoor communication devices, sensors, and control systems where dust and water ingress protection is required. The pre-molded construction reduces strain on cable terminations and helps maintain connection integrity in applications subject to vibration or repeated handling.

For applications requiring higher pin counts, different keying options, or alternative cable specifications, please consult our technical team to evaluate the appropriate connector series for your requirements.

Construction and Quality Assurance

Manufactured by Shenzhen Meiyadi Technology Co., Ltd., a professional connector and cable assembly manufacturer with over 15 years of experience, this product benefits from integrated R&D, mold development, precision manufacturing, injection molding, cable assembly, and quality inspection capabilities.

Quality control includes waterproof testing, electrical testing, mechanical testing, and dimensional inspection to verify product reliability before shipment. These validation steps help ensure consistent performance across production batches.

Customization Options

OEM/ODM services are available for cable length, wiring configuration, and connector requirements. Customized waterproof connector and cable assembly solutions can be developed for industrial automation, communication equipment, sensors, and other demanding applications worldwide.

For applications with specific mechanical or environmental requirements beyond standard specifications, please provide your detailed requirements for evaluation.

Inquiry Checklist

To receive an accurate quotation and configuration recommendation, please prepare the following information:

• Required cable length and conductor size
• Mating connector type and pinout configuration
• Operating voltage and current requirements
• Environmental conditions (temperature range, chemical exposure, UV exposure)
• Mounting method and space constraints
• Order quantity and target delivery schedule

For related connector options, review the Waterproof Connectors catalog or explore the LD20/SP20 Industrial Flange Connector Dimensions and Specs for alternative mounting configurations.
