GX16 Connectors
< >

GX16 Connector for Digital Oscilloscopes

>Number Of CoresNumber Of Cores 2-10Pins
Contact DiameterContact Diameter(mm) 1.2mm/2.5mm
IP RatingIP Rating IP55
Shell MaterialShell Material Zinc Alloy With Nickel Plated
Temperature RangeTemperature Range -30°C to +85°C
TerminationTermination Solder
Rated CurrentRated Current(A) 5A - 15A
Rated VoltageRated Voltage(Ac.V) 250V
Test VoltageTest Voltage(Ac.V)1Min 1500V
Insulation ResistanceInsulation Resistance (MΩ) ≥2000MΩ
Contact ResistanceContact Resistance (MΩ) ≤5 mΩ
CertificationCertification CE, RoHS,BASCI,ISO9001
Get Quote
+86-19924482730

GX16 Connector for Digital Oscilloscope Measurement Systems

The GX16 connector is a reliable circular connector widely used in digital oscilloscope measurement systems and other precision testing instruments. It provides stable electrical connections for signal transmission between measurement modules and external devices.

Connectors


GX16 Connector Durable Construction

Built with a rugged metal shell and high-quality contacts, the GX16 connector offers excellent durability and resistance to mechanical stress, making it suitable for laboratory environments and industrial testing applications.

GX16 Connector Reliable Locking Design

The screw locking mechanism ensures a secure connection during operation, preventing loosening caused by vibration or frequent equipment movement.

GX16 Connector Flexible Application

With multiple pin configurations available, GX16 connectors can support various signal and power transmission needs in oscilloscopes, signal analyzers, calibration instruments, and other measurement devices.

Item

Parameters

Number of Cores

2-10Pin

Gender

Male/Female

Housing Material

Zinc Alloy with Nickel Plated

Cores Material

Brass Plated with Silver/Gold

Insulator Material

Phenolics

Locking System

Screw Locking

Temperature Range

-30℃, +85℃

Rated Current (A)

5A - 15A

Rated Voltage (AC.V)

250V

Test Voltage (AV.C)1Min

1500V

Insulation Resistance (㏁)

2000㏁

Contact Resistance (㏁)

≤5㏁

Termination

Solder
