GX20 Connector for Radar Signal Processing Units

The GX20 connector is designed for radar signal processing units, providing secure and stable connections critical for high-frequency communication radar systems. Its construction targets the electrical and mechanical demands of radar installations where consistent signal integrity is essential.

Construction and Durability for Radar Environments

Engineered to withstand harsh environments, vibration, and temperature variations common in radar installations, the GX20 connector is built for long-lasting performance. The housing is constructed from zinc alloy with nickel plating, while the contacts are brass plated with silver or gold, supporting reliable conductivity in demanding conditions.

Installation and Integration Considerations

The compact design of the GX20 connector allows for quick integration into radar modules, reducing maintenance time and simplifying system setup. When planning installation, consider the following:

• Confirm the required number of cores (2-15 pin configurations are available) for your signal and power lines.
• Verify the gender (male or female) needed for your cable and panel mounting arrangement.
• Check the cable diameter and termination method against your existing wiring harness.
• Ensure the operating temperature range of the connector matches your installation environment.

Signal Transmission Performance

The GX20 connector supports high-speed signal transfer with minimal interference, helping maintain the accuracy and efficiency of radar signal processing. The silver or gold plating on the brass contacts supports stable electrical performance, which is important for preserving signal quality in sensitive radar applications.

Suitable Applications and Boundaries

This connector is well-suited for communication radar units, surveillance radar systems, and other high-performance radar equipment requiring dependable connectivity. It is not intended for applications requiring waterproof performance while unmated, nor for environments exceeding its rated temperature limits. For applications involving extreme environmental exposure or specialized mating requirements, confirm the connector's suitability with your technical team before specification.

Configuration and Ordering Information

To ensure the correct GX20 connector for your radar system, please provide the following details when making an inquiry:

• Required pin count and gender (male or female).
• Cable outer diameter and conductor size for termination.
• Mounting style: cable or panel mount.
• Specific application environment, including temperature range and vibration levels.
• Any required drawings or pinout diagrams for your system.

For related connector options, see the Aviation Plug Connectors range or explore the Communication Radar Solution for system-level guidance.
