MS27473E8B98S 3-Pin Bayonet Coupling Connector for Radar Transceiver Units

MS27473E8B98S Connector for Radar Transceiver Units

The MS27473E8B98S is a 3-pin circular connector designed for radar transceiver units in communication radar systems. Its primary role is to maintain stable signal transmission with low loss, supporting the accuracy and reliability expected in signal processing modules, control panels, and tactical radar equipment.

Key Selection Considerations

When evaluating this connector for your radar system, focus on these decision points:

• Mating and Configuration: Confirm the required gender (male or female) and the mating interface to ensure compatibility with your existing cabling or panel layout.
• Environmental Fit: Verify the operating temperature range and vibration resistance against your installation environment, especially for airborne or portable units.
• Installation Method: Determine whether you need a cable-mounted or panel-mounted version, and check the recommended cable range for termination.
• Signal Integrity: For radar applications, confirm the contact plating and material to ensure low and stable contact resistance over time.

Construction and Materials

The connector uses an aluminum alloy housing for a balance of strength and weight, suitable for rack-mounted or portable radar enclosures. The contacts are brass plated with gold, a combination chosen to support reliable electrical performance and corrosion resistance in demanding field conditions.

Application Scope and Boundaries

This connector is intended for use in land-based, airborne, and portable radar transceiver units. It is well-suited for internal signal and control connections where a compact 3-pin interface is required.

It is not designed for high-current power distribution or for applications requiring a sealed connection while unmated. For underwater or high-pressure environments, please consult our team for a sealed or specialized alternative.

Installation and Maintenance Planning

The modular design supports quick connection and disconnection, which helps reduce maintenance time during field servicing. Before installation, verify the following to avoid integration delays:

• Confirm the exact pinout and wiring diagram with your system design.
• Check the cable outer diameter against the recommended clamping range.
• Ensure the mounting hole pattern matches your panel or bulkhead.

Quality and Verification

While specific test certificates are not listed on this page, the connector is manufactured with precision craftsmanship and military-grade materials. For detailed validation data such as mating cycles or insulation resistance, please request the specific test report during your inquiry.

Inquiry Checklist

To receive an accurate quotation and technical confirmation, please prepare the following details:

• Required gender (male or female) and quantity.
• Preferred termination type (crimp or solder) and cable specifications.
• Mounting style: cable, panel, or bulkhead.
• Any specific environmental or performance test requirements.

For further assistance, please use the inquiry form or contact us via WhatsApp to discuss your radar system requirements.

For related military-grade options, review the MS27472 Military Connector series. For broader system integration, explore our Communication Radar Solution.
