M16 3 Pin Male Straight Cable Plug IP67 Waterproof Connector

GX16 Aviation Connector Types and Specifications

M16 3 Pin Male Straight Cable Plug Overview

The M16 3 Pin Male Straight Cable Plug with PA66 housing is a waterproof circular connector designed for stable AC power transmission in industrial and outdoor electrical systems. This model features a 16 mm threaded coupling interface, three male contacts, and a straight cable outlet structure.

It is engineered for applications where a compact yet higher load connector is required compared to M12 or M13 models.

3 Pin Configuration for AC Power Systems

This M16 model uses a 3 pin configuration typically designed for:

• Live
• Neutral
• Ground

The structured layout makes it suitable for single phase AC systems, industrial lighting power input, and compact machinery power modules.

Compared with 4 pin signal versions, the 3 pin structure focuses on power stability and current carrying performance rather than mixed signal integration.

Straight Cable Exit with Internal Clamp Structure

Unlike panel mount or right angle versions, this model adopts a straight cable outlet design combined with an internal cable clamp.

Key structural advantages include:

1. Improved strain relief
2. Reduced cable pull stress
3. Better sealing consistency
4. Cleaner cable routing in inline assemblies

The internal clamp prevents conductor movement and enhances long term reliability in vibrating environments.

PA66 Nylon Housing with Reinforced Thread

The housing is made of industrial grade PA66 nylon, offering a balance between mechanical strength and weight efficiency.

Material characteristics include:

1. High impact resistance
2. Strong insulation performance
3. Resistance to UV exposure
4. Corrosion free structure
5. Stable dimensional tolerance

The reinforced threaded coupling ensures secure mating and stable sealing under repeated connection cycles.

IP67 Waterproof Protection for Outdoor Use

When properly assembled and tightened, this connector achieves IP67 protection.

This provides:

1. Full dust protection
2. Resistance to temporary water immersion
3. Reliable outdoor performance
4. Extended service life in humid conditions

The sealing ring and threaded compression structure maintain waterproof integrity during operation.

Industrial and Commercial Applications

The M16 3 Pin Male Straight Cable Plug is widely used in:

1. Outdoor LED power distribution
2. Industrial automation equipment
3. Power extension assemblies
4. Garden and landscape lighting systems
5. Compact motor drive connections

Its structure makes it particularly suitable for inline cable to equipment power interfaces.

Selection Considerations and Inquiry Checklist

When selecting this M16 connector for your project, verify the following before ordering:

• Mating connector gender and configuration (panel mount or cable type)
• Cable outside diameter and conductor size for proper clamp fit
• Required current and voltage ratings for your specific load
• Environmental conditions including temperature range and exposure
• Pinout requirements and wiring diagram confirmation
• Order quantity and delivery schedule

For related connector options, explore the Aviation Plug Connectors range or review the M16 Circular Connector for Industrial Robot Control Systems in Poland case study.

Conclusion

The M16 3 Pin Male Straight Cable Plug with PA66 housing is a durable and waterproof circular connector designed for stable AC power transmission in industrial and outdoor environments. Featuring a straight cable structure, internal clamp design, and IP67 protection, it provides secure connection and long term reliability.
