SP21 Connector for Phased Array Radar Control Modules

The SP21 connector is widely used in communication radar equipment, especially in phased array radar control modules where stable signal transmission and secure connections are essential. Its robust construction ensures reliable operation in demanding military and industrial environments.

Durable SP21 Connector with Secure Thread Locking

Designed with a high-strength metal shell and threaded coupling mechanism, the SP21 connector provides strong vibration resistance and stable electrical contact. This makes it suitable for radar systems that operate on mobile platforms or in harsh outdoor conditions.

SP21 Connector for High-Performance Signal and Power Transmission

The connector supports multiple pin configurations, allowing simultaneous transmission of power and control signals in radar electronic systems. It is commonly integrated into radar control units, signal processing modules, and antenna control equipment.

Key Selection Considerations

• Confirm the required number of cores (2-12 pin range) and gender (male/female) for your radar control module interface.
• Verify the housing material (PC/PA66) and gold-plated brass contacts meet your environmental and signal integrity requirements.
• Check the thread locking mechanism compatibility with your panel mounting or cable assembly design.

Application Boundaries

The SP21 connector is suited for phased array radar control modules, signal processing units, and antenna control equipment in communication radar systems. It is not intended for applications requiring high-current power distribution or where a sealed, unmated waterproof rating is mandatory; confirm the specific IP rating for your installation environment.

Installation and Inquiry Checklist

When requesting a quotation or design validation, provide the following details to ensure correct mating and performance:

• Required pin count and gender configuration.
• Cable outer diameter and conductor gauge for termination planning.
• Mounting style (panel mount, cable mount, or free hanging).
• Operating temperature range and vibration profile of the radar platform.
• Any specific sealing or environmental protection requirements.

For related radar connector configurations, review the MS27508 Military Connectors Configurations and Specifications or explore the Aviation Plug Connectors range for alternative mounting and coupling options.
