M12 Connector
< >

M12 2-17 Pin Straight Assembly Cable Connector Waterproof

>Number Of CoresNumber Of Cores 2-17 Pin
Contact DiameterContact Diameter(mm) 0.6mm
IP RatingIP Rating IP67
Shell MaterialShell Material PA66/Nickel Plated Brass
Temperature RangeTemperature Range -40℃ ~ +85℃
TerminationTermination Solder
Rated CurrentRated Current(A) 1A
Rated VoltageRated Voltage(Ac.V) 125V
Test VoltageTest Voltage(Ac.V)1Min 1000V
Insulation ResistanceInsulation Resistance (MΩ) 1500MΩ
Contact ResistanceContact Resistance (MΩ) ≤10MΩ
CertificationCertification CE,ISO9001, RoHS
Get Quote
+86-19924482730

M12 2 - 17 Pin Straight Assembly Cable Connector Waterproof – Industrial-Grade Reliable Connectivity
The M12 2–17 Pin Straight Assembly Cable Connector Waterproof is designed for industrial and automation systems requiring flexible pin options, secure cable connection, and dependable waterproof protection. Its straight assembly design allows for direct cable routing, making it ideal for machinery, sensors, and control systems where stable electrical performance and durability are essential.
M12 Connector
Unlike conventional straight connectors, this M12 model combines wide pin range adaptability with IP67-level environmental protection, ensuring reliable operation in harsh industrial settings.

Engineered for Harsh Industrial Environments
Industrial equipment and automation systems often operate under vibration, moisture, and dust exposure. This connector is developed to provide:
Stable electrical transmission for power, signal, or mixed lines
Secure cable integration in tight machinery layouts
Reliable performance under vibration, dust, or water exposure

Reduced downtime through robust design and easy field assembly


Its straight configuration is especially suitable for applications requiring organized cable routing without compromising panel or device layout.

Flexible Pin Options (2 -17 Pins)
The wide pin range makes this connector suitable for diverse industrial applications:
2 - 3 Pins: Basic power supply
4 - 8 Pins: Combined power and signal lines

9 - 17 Pins: Multi-signal transmission for complex control systems

Connector

This flexibility allows manufacturers to standardize connectors across multiple equipment types, reducing inventory complexity and installation time.

Key Product Features
Waterproof IP67 Protection
Sealed housing ensures safe operation in wet, dusty, or harsh environments.

Straight Assembly Cable Design
Supports direct cable integration for easy installation and efficient wiring.

Durable Industrial Housing
Reinforced materials and precision contacts provide long-term reliability under mechanical stress.

Wide Compatibility
Ideal for sensors, automation systems, robotic controls, and industrial machinery.

Precision Contact System
Stable conductivity ensures consistent signal and power transmission, even in high-demand operations.

Factory Manufacturing Strength
We are a professional connector manufacturer with over 15 years of experience in industrial connectors and cable assembly solutions.
Connector
Our factory integrates a complete production workflow:
Mold and tooling development
CNC machining and precision housing fabrication
Injection molding for insulating components
Cable assembly and connector integration

Rigorous functional and environmental testing

Circular Connector

This vertical manufacturing capability ensures consistent product quality, reliable supply, and flexible OEM/ODM customization.

Strict Quality Control
Each connector undergoes comprehensive testing:
IP67 waterproof sealing verification
Electrical continuity and contact resistance testing
Plugging and mating cycle durability assessment
Vibration and mechanical stress resistance testing

Dimensional and structural inspection

Connector

All products comply with ISO9001, CE, and RoHS standards, meeting international industrial requirements.
Connector
Customization Options
We offer OEM/ODM services tailored for industrial applications:
Custom pin configuration (2 - 17 pins)
Cable length and wire specification adjustments
Shielded or anti-interference cable solutions
Housing and structural customization
Application-specific connector design
Our engineering team supports projects from prototype development to large-scale production.

Application Areas
Industrial automation systems
Robotic and motion control equipment
Sensor and actuator networks
PLC and panel control connections
Smart manufacturing devices
Data acquisition and monitoring systems
Reliable Industrial Cable Connection
The M12 2 - 17 Pin Straight Assembly Cable Connector Waterproof is built to provide versatile, durable, and high-performance connectivity for modern industrial and automation equipment.

Contact Us
We provide samples, technical support, and customized production services.
Contact us today for factory-direct M12 connector solutions and competitive quotations.

 Item

 Parameters

 Number of Cores

 2-17Pin

 Gender

 Male/Female

 Housing Material

 PA66/Nickel Plated Brass

 Cores Material

 Brass Plated with Silver/Gold

 Insulator Material

 Phenolics

 Locking System

 Screw Locking

 Temperature Range

 -40℃~+85℃

 Rated Current (A)

 1A

 Rated Voltage (AC.V)

 125V

 Test Voltage (AV.C)1Min

 1000V

 Insulation Resistance (㏁)

 1500㏁

 Contact Resistance (㏁)

 ≤10㏁

 Termination

 Solder
