GX16 Connector for CCTV Cameras and Surveillance Systems

SF Series Aviation Connectors Specifications and Performance Data

GX16 Connector for CCTV Cameras and Surveillance Systems

The GX16 connector is a circular connector designed for professional security monitoring systems. Its construction supports reliable connections for CCTV cameras, PTZ cameras, DVR systems, and other surveillance equipment. This page helps buyers evaluate interface, electrical, environmental, and installation factors before selecting a connector.

Construction and Materials

The GX16 connector uses a zinc alloy housing with nickel plating, providing corrosion resistance for indoor and outdoor installations. Contact cores are brass with silver or gold plating, supporting stable electrical performance. The insulator material is selected for reliable signal integrity in continuous monitoring applications.

Selection Considerations for Surveillance Applications

• Pin count: Available in 2 to 10 pin configurations; confirm the number of cores required for your camera or DVR wiring before ordering.
• Gender: Choose male or female versions according to your cable and panel mounting requirements.
• Mating compatibility: Verify the connector series and pin layout against your existing equipment; do not assume compatibility based on appearance alone.
• Environmental fit: Confirm the operating temperature range and any required ingress protection rating for outdoor installations.

Installation and Wiring

The GX16 connector is designed for straightforward field wiring. Solder or crimp termination methods are typical for this series. Prepare the cable according to the contact diameter and wire gauge specified in the technical datasheet. For PTZ cameras or pan-tilt mechanisms, confirm that the connector's mechanical dimensions allow proper cable routing and movement clearance.

Suitable and Unsuitable Applications

Suitable: Fixed CCTV cameras, DVR connections, access control devices, and indoor or sheltered outdoor surveillance equipment where the connector's environmental rating matches the installation conditions.

Unsuitable: Applications requiring submersion, high-vibration environments, or extreme temperature ranges beyond the connector's verified ratings. For fully waterproof outdoor camera installations, consider connectors with a higher IP rating.

Buyer Inquiry Checklist

To receive an accurate quotation and matching recommendation, provide the following information:

• Required pin count and gender (male/female)
• Cable diameter and conductor gauge
• Mounting style: panel mount, cable mount, or inline
• Operating environment: indoor, outdoor, temperature range
• Any specific IP rating or material requirements

For related guidance on connector selection for outdoor surveillance, see M8 or M12 connector selection for outdoor cameras. For a broader view of circular connector options, review the 12G Series circular connectors.
