IP67 GX16 Connector for Solar Tracker Motors

Name: IP67 GX16 Connector for Solar Tracker Motors
Brand: KMYD
SKU: 2-10Pins
Price: 1.00 USD
Availability: InStock
Rating: 4.9 (12 reviews)

MOQ	>200
Price
Number Of Cores	2-10Pins
Contact Diameter(mm)	1.2mm/2.5mm
IP Rating	IP55
Shell Material	Zinc Alloy With Nickel Plated
Temperature Range	-30°C to +85°C
Termination	Solder
Rated Current(A)	5A - 15A
Rated Voltage(Ac.V)	250V
Test Voltage(Ac.V)1Min	1500V
Insulation Resistance (MΩ)	≥2000MΩ
Contact Resistance (MΩ)	≤5 mΩ
Certification	CE, RoHS,BASCI,ISO9001

Get Quote

+8619924482730

LD20/SP20 Industrial Flange Connector

GX16 Connector for Solar Tracker Motors

The GX16 connector is a circular, multi-pin interface engineered for reliable power and signal transmission in solar tracker motor systems. Its construction prioritizes mechanical stability and environmental sealing, making it a practical choice for outdoor renewable energy installations where vibration and weather exposure are routine.

Selecting the Right GX16 Configuration

Choosing the correct GX16 connector begins with matching the pin count and gender to your motor's wiring and control board. The series supports 2 to 10 cores, with male and female variants available to suit cable-to-panel or cable-to-cable connections.

Pin Count: Verify the number of cores required by your motor's power and feedback lines before ordering.
Gender: Confirm whether your application needs a male plug or female socket on the cable side.
Termination: Ensure the contact style matches your wire gauge and soldering or crimping process.

Application Fit for Solar Tracking Systems

Solar tracker motors operate in environments with significant temperature swings, UV exposure, and potential moisture. The GX16 connector's IP67 rating provides a defined level of protection against dust and temporary water immersion, which is essential for maintaining uptime in exposed installations.

For engineers integrating this connector, consider the cable entry orientation and the available space inside the junction box. The connector's compact circular form factor supports routing in tight spaces, but the mating depth and locking mechanism should be verified against your enclosure design.

Construction and Material Integrity

The housing is manufactured from zinc alloy with a nickel-plated finish, offering a balance of mechanical strength and corrosion resistance. Contacts are made of brass with silver or gold plating, which supports consistent conductivity over repeated mating cycles.

This material combination is selected to withstand the mechanical stress of vibration and the thermal cycling common in solar farm environments. The insulator material provides electrical isolation between cores, reducing the risk of short circuits during operation.

Suitable and Unsuitable Use Cases

Suitable: The GX16 connector is well-suited for fixed and single-axis solar tracker motors, control signal wiring, and low-to-medium current power connections within the specified electrical limits.

Unsuitable: It is not intended for high-current main power distribution, submersible applications beyond its IP67 rating, or environments with continuous chemical exposure that could degrade the nickel plating. For applications requiring higher pin density or different sealing, consider alternative series.

Information to Include in Your Inquiry

To ensure accurate matching and timely supply, please provide the following details when requesting a quote or sample:

Required pin count and gender (male/female) for both cable and panel sides.
Wire gauge and insulation diameter for termination planning.
Operating voltage and current for your specific motor model.
Environmental conditions, including expected temperature range and exposure to moisture or dust.
Any specific mounting requirements, such as panel thickness or cable entry angle.

For related industrial flange connector options, you may review the Waterproof Connectors catalog or the LD20/SP20 Industrial Flange Connector for higher-current applications.

GX16 Aviation Connector

Item	Parameters
Number of Cores	2-10 Pin
Gender	Male / Female
Housing Material	Zinc Alloy with Nickel Plated
Cores Material	Brass Plated with Silver / Gold
Insulator Material	Phenolics
Locking System	Screw Locking
Temperature Range	-30°C to +85°C
Rated Current (A)	5A - 15A
Rated Voltage (AC.V)	250V
Test Voltage (AC.V) 1 Min	1500V
Insulation Resistance (MΩ)	2000 MΩ
Contact Resistance (MΩ)	≤5 MΩ
Termination	Solder
