MIL-DTL-5015 Connector
< >

MIL-DTL-5015 Connector for Industrial Motor Control Systems

MOQMOQ >200
PricePrice
>Number Of CoresNumber Of Cores 2-52Pin
Contact DiameterContact Diameter(mm) 1.5mm/2.5mm/3.5mm
IP RatingIP Rating IP67
Shell MaterialShell Material Aluminum Alloy
Temperature RangeTemperature Range -55℃ ~ +125℃
TerminationTermination Solder
Rated CurrentRated Current(A) 5A-50A
Rated VoltageRated Voltage(Ac.V) 500V-2000V
Test VoltageTest Voltage(Ac.V)1Min 1500V
Insulation ResistanceInsulation Resistance (MΩ) ≥5000MΩ
Contact ResistanceContact Resistance (MΩ) ≤2.0 mΩ
CertificationCertification CE, RoHS,BASCI,ISO9001
Get Quote
+8619924482730

MIL-DTL-5015 Connector for Industrial Motor Control Systems

The MIL-DTL-5015 connector for industrial motor control systems is a heavy-duty circular connector designed for reliable electrical connections in demanding electronic control applications. Built to military specifications, it offers exceptional durability and stable performance in industrial environments.

Connectors


Reliable Connection for Motor Control Equipment

These connectors are widely used in industrial motor control systems, PLC control cabinets, motor drive units, and power control panels. The threaded coupling mechanism ensures a secure and vibration-resistant connection, making it suitable for critical automation equipment.

Rugged Design for Industrial Environments

The MIL-DTL-5015 circular connector features a robust metal shell that provides excellent mechanical strength and resistance to dust, vibration, and harsh operating conditions, ensuring long-term reliability in industrial automation systems.

Item

Parameters

Number of Cores

2-52Pin

Gender

Male/Female

Housing Material

Aluminum Alloy

Cores Material

Brass Plated with Gold

Insulator Material

PPS/PEI

Locking System

Bayonet Locking

Temperature Range

-55℃, +125℃

Rated Current (A)

5A-50A

Rated Voltage (AC.V)

500V-2000V

Test Voltage (AV.C)1Min

1500V

Insulation Resistance (㏁)

≥5000㏁

Contact Resistance (㏁)

≤20㏁

Termination

Solder
