WS28 2-12 Pin Aviation Connector for Industrial Power Control

SF Series Aviation Connectors Specifications and Performance Data

WS28 2-12 Pin Aviation Connector for Industrial Power Control Systems

The WS28 series aviation connector provides a 2-12 pin configuration for industrial power control systems. It is designed for applications requiring secure screw locking and a durable metal housing. This connector supports both male and female genders, with a zinc alloy housing featuring chrome plating for enhanced environmental resistance.

This connector is suitable for engineers and maintenance professionals who need a reliable circular interface for power and control circuits in industrial equipment. Its construction focuses on stable electrical transmission and mechanical robustness for demanding operational environments.

Selection and Configuration Guidance

When selecting the appropriate WS28 connector, consider the following decision points to ensure proper system integration:

• Pin Count: Choose between 2 and 12 pins based on the number of circuits required for your power and control signals.
• Gender: Determine whether a male (plug) or female (socket) configuration is needed for your cable and panel mounting setup.
• Locking Mechanism: The screw locking system provides a secure connection, suitable for applications with vibration or where accidental disconnection must be prevented.
• Environmental Fit: The zinc alloy housing with chrome plating offers protection against industrial contaminants, but verify the specific IP rating against your installation environment.

Application Boundaries and Installation Notes

This connector is intended for use in industrial power control systems, including control cabinets, automation equipment, and machinery interfaces. It is not designed for high-flex cable applications or environments requiring submersion protection beyond the specified IP rating.

For installation, ensure the cable outside diameter and conductor size are compatible with the connector's termination range. Proper mating requires aligning the keyway before engaging the screw locking mechanism. Confirm the pinout and wiring diagram before final assembly to avoid connection errors.

Quality and Manufacturing Evidence

The WS28 connector is produced in an integrated manufacturing facility that includes precision mold development, CNC machining, die-casting, and assembly workshops. This in-house production system allows for control over quality and customization processes.

Each connector undergoes multiple testing procedures, including electrical conductivity, plugging durability, and salt spray corrosion testing. These tests are part of the factory's quality control measures to verify performance under specified conditions.

Customization and Project Support

OEM and ODM customization services are available for this connector series. Options include pin configuration adjustment, cable assembly integration, and special housing finishes. The engineering team can support projects from prototype development to mass production.

For a complete solution, consider related products in the 12G Series Circular Connectors for alternative pin configurations. For detailed specifications on similar aviation connectors, refer to the SF Series Aviation Connectors Specifications and Performance Data.

Inquiry Checklist for Accurate Quotation

To receive an accurate quotation and technical support, please prepare the following information:

• Required pin count and gender (male/female) for both mating ends.
• Cable outside diameter and conductor size (AWG or mm²).
• Electrical load (current and voltage) for the application.
• Environmental conditions (temperature, humidity, exposure to chemicals).
• Required order quantity and any customization needs.
