SD13/SP13 1-7 Pin IP68 Docking Wire Connector

SD13/SP13 Circular Docking Connector

SD13/SP13 1-7 Pin Docking Wire Connector IP68 – Compact Sealed Plug-in Solution

The SD13/SP13 1-7 Pin IP68 Docking Wire Connector is designed for equipment that requires a small-size, fast-mating, and fully sealed wire-to-wire connection. It combines a compact housing with a precise docking structure, making it suitable for portable devices, modular equipment, and systems where frequent connection and disconnection are required.

With support for 1-7 pins, this series offers flexible configuration from simple power transmission to compact multi-signal integration, while maintaining strong waterproof performance for harsh environments.

Designed for Fast Assembly and Modular Equipment

Unlike panel-mounted or fixed-installation connectors, this docking wire connector is focused on system mobility and quick deployment. It is particularly suitable for applications where equipment modules need to be connected, replaced, or serviced on-site.

The design helps engineers achieve:

• Faster system assembly and disassembly
• Flexible module-level wiring connections
• Reduced installation complexity
• Stable performance in portable or field-use equipment

Key Functional Characteristics

IP68 Full Waterproof Protection

Sealed structure effectively blocks water, dust, and environmental interference, ensuring stable operation in outdoor and industrial conditions.

Compact SD13/SP13 Design

Small housing size makes it ideal for equipment with strict space limitations while maintaining mechanical durability.

1-7 Pin Flexible Configuration

• Low pin count for simple power applications
• Medium configuration for power + signal systems
• Higher pin count for compact multi-channel transmission

Docking Wire-to-Wire Structure

Enables quick connection between cable assemblies without fixed installation, improving flexibility in system design.

Stable Mechanical Mating

Precision alignment structure ensures reliable connection even after repeated plugging cycles.

Manufacturing Strength Behind the Product

We are a professional connector manufacturer with over 15 years of experience in waterproof connectors and cable assembly solutions, serving industrial automation, smart devices, energy systems, communication equipment, and portable electronics industries.

Our factory operates a fully integrated production system, including:

• Mold design and tooling development
• Zinc alloy die-casting
• CNC precision machining
• Injection molding
• Cable processing and connector assembly

This vertical manufacturing capability ensures consistent product quality, stable production capacity, and reliable delivery performance for global customers.

Strict Quality Control System

Each SD13/SP13 docking connector undergoes rigorous testing before shipment:

• IP68 waterproof sealing test
• Electrical continuity and conductivity testing
• Plugging and docking cycle durability test
• Mechanical vibration resistance test
• Dimensional accuracy inspection

All products are manufactured under ISO9001 quality management standards and comply with CE and RoHS international certifications.

Customization Support

We provide flexible OEM/ODM services to meet different project requirements:

• Cable length and wire specification customization
• Pin configuration optimization (1-7 pins)
• Shielded and anti-interference solutions
• Overmolding and structural design support
• Application-specific connection development

Our engineering team supports customers from prototype stage to mass production.

Application Areas

• Portable industrial equipment
• Modular electronic systems
• Outdoor mobile devices
• Smart sensors and control modules
• Temporary field installation systems
• Compact automation equipment

Selection Considerations

When selecting the SD13/SP13 docking connector for your project, verify the following parameters against your application requirements:

• Confirm the required pin count (1-7) matches your power and signal channels
• Check that the threaded locking system suits your vibration and pull-force environment
• Verify the PA66/PA6 housing and PPS insulator materials are compatible with your operating temperature range
• Confirm the brass silver-plated contacts meet your conductivity and corrosion-resistance needs
• Ensure the IP68 rating aligns with your submersion depth and duration requirements

Inquiry Checklist

To receive an accurate quotation and technical recommendation, please provide the following information:

• Required pin count and pinout configuration
• Cable outside diameter and conductor size
• Electrical load (current and voltage)
• Mating-side connector requirement (male or female)
• Operating environment and IP protection needs
• Order quantity and target delivery timeline

For related options, review the Banana plug Series Connectors or the SD13/SP13 Circular Docking Connector for additional configuration details.

A Flexible Connection Solution for Modern Systems

The SD13/SP13 IP68 docking wire connector is designed to provide a compact, fast-connect, and highly reliable wiring solution, making it ideal for modular and portable system architectures.

Contact Us

We provide samples, technical support, and customized production services. Contact us today for professional connector solutions and quotation support.
