GOST PC Series Connectors 4-50 Pin Screw Locking for Rail Transit

GOST OHS Circular Connector with Multiple Core Count Options

GOST PC Series Connectors – Rugged and Reliable for Rail Transit

The GOST PC Series Connectors are engineered for demanding rail transit applications, providing secure and stable connections for power, signal, and control circuits. Designed to meet Russian GOST standards, these connectors withstand vibration, shock, dust, and moisture, making them suitable for locomotives, trackside systems, and onboard electronics.

Selecting the Right Pin Configuration

Available in multiple pin configurations, from PC4TB (4 pins) for small control circuits to PC50TB (50 pins) for complex multi-signal harnesses, the PC series supports a wide range of electrical needs. High-quality copper alloy contacts with gold or silver plating, paired with durable PBT or bakelite insulation, ensure reliable conductivity under varying loads.

Construction and Environmental Resistance

With threaded locking mechanisms, corrosion-resistant aluminum alloy shells, and versatile multi-pin layouts, the PC Series provides long-lasting, dependable performance. These connectors are designed for brake systems, signaling circuits, sensors, and power distribution panels, helping engineers maintain safety, uptime, and efficiency in rail applications.

Key Decision Points for Buyers

• Pin count and layout: Match the core count to your circuit complexity—4-pin for simple control, up to 50-pin for dense signal harnesses.
• Contact plating: Gold plating offers superior corrosion resistance for signal integrity; silver plating is a cost-effective option for power circuits.
• Locking mechanism: Threaded screw locking provides vibration resistance essential for locomotive and trackside environments.
• Insulation material: PBT suits general industrial use; bakelite offers higher heat resistance for demanding applications.

Suitable and Unsuitable Applications

The PC Series is well-suited for rail transit systems requiring robust, dust- and moisture-resistant connections under mechanical stress. They are not intended for submersible or high-pressure washdown environments where a higher IP-rated sealed connector would be required. For applications outside rail transit, verify the environmental and electrical requirements against the Technical Specifications before selection.

Installation and Mating Considerations

Before ordering, confirm the mating gender (male/female), cable entry orientation, and panel cutout dimensions. For field assembly, ensure the recommended crimp tooling and torque values are available. If you are replacing an existing connector, provide the current pinout diagram and cable diameter to verify compatibility.

Inquiry Checklist

To receive an accurate quotation and mating recommendation, please provide the following information:

• Required pin count and gender (male/female)
• Cable outer diameter and conductor cross-section
• Operating voltage and current per contact
• Ambient temperature range and exposure to chemicals or moisture
• Mounting style: cable-to-cable, panel mount, or bulkhead
• Any existing drawings or pinout diagrams

For related Russian standard connector options, see the GOST OHS Circular Connector with Multiple Core Count Options. For rail transit applications, review the 12G Series Circular Connectors for alternative environmental sealing performance.
