10 Pin WY20 Aviation Connector with Customized Wire

SD20/SP20 Square Flange Connector Design and Installation Guide

WY20 10-Pin Aviation Connector with Customized Cable Assembly

The 10 Pin WY20 Aviation Connector with Customized Wire is a circular, threaded-locking connector designed for secure power and signal transmission in industrial equipment. Its rugged aluminum alloy housing and integrated cable assembly provide mechanical strength and connection stability for demanding environments. This connector is supplied as a complete, customized wiring solution to simplify installation and reduce wiring errors.

Key Selection Criteria for the WY20 Series

When evaluating this connector for your application, consider the following decision points:

• Pin Configuration: The 10-pin layout supports basic power supply or simple signal circuits. Confirm your required pinout and gender (male/female) for the mating pair.
• Mechanical Protection: The metal housing and threaded locking mechanism prevent loosening from vibration, ensuring a durable connection in industrial settings.
• Cable Integration: Customized cable assemblies are available with options for length, material (PVC, rubber, PUR), wire gauge, and straight or angled outlets to match your equipment layout.
• Application Fit: This connector is suitable for industrial machinery, control equipment, electrical cabinets, LED lighting, and testing devices where a secure, reliable connection is required.

Customization Options for Your Wiring Needs

This connector is typically provided as a complete cable solution tailored to specific installation requirements. Available customization options include:

• Custom cable length according to equipment layout
• PVC, rubber, or PUR cable material selection
• Different wire gauges for various electrical loads
• Straight or angled cable outlet configurations
• Shielded cable options for signal stability
• OEM branding and packaging support

These flexible options make the connector adaptable to both standard production and specialized engineering projects.

Manufacturing and Quality Assurance

Our factory specializes in the production of circular connectors and customized cable assemblies for industrial applications. With integrated manufacturing processes and strict quality control, we ensure stable product performance and consistent delivery for customers worldwide.

Manufacturing strengths include:

• Integrated connector and cable assembly production
• Skilled wiring and termination processes
• Stable batch consistency for repeat orders
• Flexible production for customized requirements
• Efficient order handling for OEM projects

Each WY20 connector assembly is tested to ensure dependable operation in real working conditions. Quality checks include electrical continuity and insulation testing, mechanical connection durability testing, cable termination reliability inspection, and visual and dimensional quality control.

Application Boundaries and Suitability

The 10 Pin WY20 aviation connector with customized wire is widely used in equipment that requires secure and durable electrical connections, such as:

• Industrial machinery and automation systems
• Power supply and control equipment
• Electrical cabinets and distribution systems
• LED lighting and display devices
• Testing and measurement equipment
• Mechanical and transportation equipment

This connector is not intended for high-frequency signal transmission or applications requiring waterproof performance while unmated. For those requirements, please consult our technical team for alternative solutions.

Inquiry Checklist for Accurate Quotation

To receive a precise quotation and ensure the correct configuration, please provide the following information when making an inquiry:

• Mating-side requirement (connector gender and series)
• Pinout or wiring diagram
• Cable outside diameter and conductor size
• Electrical load (current and voltage)
• Environmental conditions (temperature, exposure)
• Order quantity and target delivery date

For more information on connector configurations and specifications, please refer to our Aviation Plug Connectors catalog. For a related solution, see our WY20 10 Pin Aviation Circular Cable Connector OEM/ODM page.
