SY17 and SY21 Circular Connectors for Smart Security Cameras

PC Series Circular Connector Types and Specifications

SY Series Circular Connectors in Smart Security Camera Systems

SY17 and SY21 circular connectors are widely adopted in smart security camera systems to establish dependable connections between cameras, control panels, and power units. Their bayonet locking mechanism enables rapid, secure mating, reducing installation time on-site while preventing accidental disconnection during operation.

Project Background and Industry Context

In modern surveillance infrastructure, cameras are often deployed in semi-outdoor or humid environments such as building entrances, parking garages, and perimeter monitoring points. These locations demand connectors that can withstand moisture exposure while maintaining uninterrupted signal and power transmission. The SY series connectors are selected for such applications due to their robust mechanical design and environmental sealing.

Customer Requirements and Electrical Specifications

The primary requirements for the connector solution included:

• Reliable power and signal transmission between the camera unit and the control panel.
• Secure mating to prevent loosening from vibration or incidental cable pulls.
• Environmental protection suitable for humid or semi-outdoor installations.
• Fast and straightforward installation to support efficient system deployment.

While specific electrical load values are not disclosed in the source material, the SY17 and SY21 series are designed to support typical low-voltage power and signal interfaces used in security camera systems. For detailed electrical ratings, please refer to the product datasheet or contact our engineering team.

Solution and Connector Configuration

The SY17 and SY21 connectors feature a bayonet locking mechanism, which provides a positive and audible click upon full engagement. This design simplifies field installation and ensures a stable connection over extended service periods. The connectors are available in configurations suitable for cable-to-panel or cable-to-cable connections, depending on the system architecture.

Environmental Performance and IP67 Protection

With an IP67 protection rating, these connectors maintain reliable operation even in humid or semi-outdoor environments. The sealing design prevents ingress of dust and temporary water immersion, ensuring continuous surveillance performance in challenging conditions. It is important to note that the IP67 rating applies when the connector is properly mated; unmated connectors do not retain the same level of protection.

Installation and Commissioning Notes

During installation, ensure that the connector is fully rotated until the bayonet lock engages. Verify that the cable gland or strain relief is correctly tightened to maintain the environmental seal. For semi-outdoor installations, position the connector to avoid direct water pooling on the mating interface where possible.

Related Resources

For further guidance on selecting the appropriate circular connector for your surveillance application, you may refer to the following resource: For outdoor surveillance cameras, should M8 or M12 connectors be selected?

Next Steps

If you are evaluating connectors for a security camera system or a similar application, please provide your electrical load, cable diameter, and environmental requirements. Our team can assist in confirming the suitable connector configuration and mating accessories. Use the inquiry form or contact us via WhatsApp to discuss your project details.
