MS27508E14B35P MIL-Spec Circular Connector, 37-Pin Bayonet Coupling

MOQMOQ >200
PricePrice
>Number Of CoresNumber Of Cores 37Pins
Contact DiameterContact Diameter(mm) 1.02mm
IP RatingIP Rating IP67
Shell MaterialShell Material Aluminum Alloy
Temperature RangeTemperature Range -65℃ ~ +200℃
TerminationTermination Crimp
Rated CurrentRated Current(A) 5A
Rated VoltageRated Voltage(Ac.V) 500V
Test VoltageTest Voltage(Ac.V)1Min 1500V
Insulation ResistanceInsulation Resistance (MΩ) ≥5000MΩ
Contact ResistanceContact Resistance (MΩ) ≤ 5 mΩ
CertificationCertification CE, RoHS,BASCI,ISO9001
Get Quote

MS27508E14B35P MIL-Spec Connector Overview

The MS27508E14B35P is a MIL-Spec circular connector engineered for electronic control systems that demand dependable performance. This 37-pin bayonet coupling connector is designed for secure, stable signal transmission in critical applications.

MS27508E14B35P MIL-Spec circular connector for electronic control systems

Key Selection Criteria for Your Control System

When evaluating this connector for your project, consider these decision points:

  • Pin Configuration: The 37-pin layout supports complex control signal routing, but verify your exact pinout requirements against the connector's arrangement.
  • Mating Compatibility: This male/female connector uses bayonet coupling. Confirm your mating connector part number to ensure a proper fit.
  • Environmental Fit: The aluminum alloy housing is built for demanding conditions, but assess your specific temperature, vibration, and exposure requirements.
  • Installation Method: Consider whether your application needs cable or panel mounting and how the connector integrates with your existing wiring.

Construction and Materials

The connector features an aluminum alloy housing, providing a robust shell for internal components. This material choice supports durability in harsh environments typical of military and industrial settings. The core material specifications are detailed in the Technical Specifications section.

Application Boundaries

Suitable for: Electronic control systems in aerospace, military, and critical industrial electronics where reliable signal transmission is essential.

Not suitable for: Applications requiring high-current power transmission, as this connector is designed for signal-level circuits. Always verify current and voltage ratings against your load requirements.

Installation and Maintenance Considerations

The user-friendly bayonet coupling design simplifies assembly and maintenance. For installation planning, prepare the following:

  • Confirm the cable outside diameter and conductor size for proper termination.
  • Verify the required mounting style (cable or panel) for your enclosure.
  • Ensure the mating connector part number matches this MS27508E14B35P configuration.

Inquiry Checklist

To receive an accurate quotation and compatibility confirmation, please provide:

  • Your mating connector part number and gender
  • Pinout diagram or wiring requirements
  • Cable outside diameter and conductor size
  • Electrical load (current and voltage) for your application
  • Environmental conditions (temperature range, exposure to moisture or chemicals)
  • Required order quantity

For related MIL-Spec connector options, review the MS27467 Circular Connectors catalog. For a similar connector with a different configuration, see the MS27508E14B35S MIL-Spec Circular Connector, 37-Pin Bayonet Coupling.

Contact our team or use the inquiry form to confirm the MS27508E14B35P meets your specific control system requirements before ordering.

Item Parameters
Number of Cores 37 Pins
Gender Male/Female
Housing Material Aluminum Alloy
Cores Material Brass Plated with Gold
Insulator Material PEFT
Locking System Bayonet Coupling
Temperature Range -65°C to +200°C
Rated Current (A) 5A
Rated Voltage (AC.V) 500V
Test Voltage (AC.V) 1 Min 1500V
Insulation Resistance (MΩ) 5000 MΩ
Contact Resistance (MΩ) ≤5 MΩ
Termination Crimp
