MS27467E13B35SB 22-Pin Aerospace Circular Connector

Din Circular Connector

MS27467E13B35SB Circular Connector Overview

The MS27467E13B35SB is a high-reliability circular connector engineered for critical aerospace applications. Its military-grade aluminum alloy shell and IP67 design support stable performance under vibration, temperature changes, and harsh environments. This 22-pin plug is intended for buyers who need a dependable interface for flight control, avionics, and sensor systems where connection integrity is non-negotiable.

Primary Applications

This connector is suited to several demanding onboard systems:

• Avionics Systems: Provides secure connections for navigation, communication, and control devices.
• Flight Control Modules: Ensures reliable links for sensors, actuators, and control surfaces.
• Radar & Sensor Systems: Maintains precise signal integrity for monitoring and detection equipment.
• Cockpit Instrumentation: Compact, easy-to-install connector for critical cockpit electronics.

Key Selection Considerations

Before specifying this connector, review the following decision points against your system requirements:

• Mating Configuration: Confirm the plug-to-receptacle interface and locking mechanism match your panel or cable assembly design.
• Contact Arrangement: Verify the 22-pin layout and gender orientation align with your wiring schematic and pinout requirements.
• Environmental Exposure: The IP67 rating applies to mated conditions; assess whether your installation requires additional sealing for unmated or high-humidity scenarios.
• Termination Method: Ensure your tooling and assembly process are compatible with the contact termination style specified for this series.

Construction and Material Highlights

The connector's design balances ruggedness with weight efficiency:

• Rugged & Lightweight: Durable aluminum alloy housing with corrosion resistance suited to airborne environments.
• Secure & Dependable: Gold-plated brass contacts support stable signal transmission for mission-critical links.
• Versatile Installation: Suitable for a range of avionics and aircraft instrumentation mounting layouts.

Suitability Boundaries

This connector is appropriate for flight control, avionics, and sensor applications that require a compact, sealed circular interface. It is not intended for high-current power distribution or for installations where the connector will remain unmated in wet or dusty conditions. Confirm the operating temperature range and vibration profile of your specific mounting location before finalizing the design.

Inquiry Checklist

To receive an accurate quotation and mating recommendation, please prepare the following details:

• Complete mating receptacle part number or series reference.
• Required pinout diagram or wiring schematic.
• Cable diameter and conductor insulation specifications.
• Mounting style (panel, cable, or free-hanging) and available space.
• Environmental requirements beyond the standard IP67 rating.

For related high-density circular options, review the 12G Series Circular Connectors or consult the Din Circular Connector catalog for alternative configurations.
