WF28 Aviation Connector Industrial Circular Power and Signal Plug

SF Series Aviation Connectors Specifications and Performance Data

WF28 Aviation Connector Overview

The WF28 Aviation Connector is a large-size threaded circular connector engineered for industrial power transmission and multi-signal control systems. Compared with smaller aviation plug models, the WF28 series offers a larger contact diameter and higher current-carrying capability, making it suitable for equipment requiring stable electrical performance and strong mechanical fixation.

It is commonly used in automation machinery, power distribution units, testing equipment, and industrial control cabinets.

Strong Threaded Coupling for Secure Locking

The WF28 aviation plug adopts a precision threaded locking mechanism to ensure firm mating between plug and socket. This design delivers several operational advantages:

• Anti-vibration performance in heavy machinery
• Stable retention under cable tension
• Reduced risk of accidental disconnection
• Clear mechanical engagement during installation

This locking structure makes the WF28 connector ideal for applications where stable long-term electrical connection is critical.

High Current Capacity with Larger Contact Structure

One of the core advantages of the WF28 circular connector is its larger internal contact design. Key structural features include:

• Increased contact diameter for improved conductivity
• Optimized contact spacing for electrical safety
• Support for higher rated current compared to smaller models
• Suitable for mixed power and signal transmission

The WF28 series can be configured for power circuits, motor interfaces, and control signal integration in a single connector body.

Durable Metal Shell for Industrial Protection

The connector housing is manufactured using a metal shell structure, providing:

• Mechanical strength against impact
• Basic EMI shielding capability
• Wear resistance in frequent connection cycles
• Long service life in factory environments

When properly installed, the WF28 aviation connector can meet industrial protection requirements depending on configuration and sealing design.

Multiple Contact Configurations

The WF28 connector is available in multiple contact arrangements to meet different wiring demands. Typical applications include:

• Industrial power input
• Equipment output interface
• Motor control wiring
• Automation signal routing

Contact quantity varies depending on engineering requirements. Custom layouts can be developed for OEM projects.

Flexible Termination and Mounting Options

To adapt to different installation methods, the WF28 series supports:

• Cable plug versions
• Panel mount receptacle versions
• Rear panel installation
• Solder termination
• Crimp termination (depending on structure)

This flexibility allows easy integration into control cabinets, distribution panels, and equipment housings.

Factory Strength - More Than Just Connector Manufacturing

We are not only a connector supplier, but also a professional industrial connectivity manufacturer with complete in-house production capabilities.

Independent Mold Development

Our engineering team develops molds internally, allowing faster product upgrades, customized structures, and better dimensional consistency.

Integrated Production System

The factory includes CNC machining workshops, die-casting departments, injection molding production lines, cable assembly workshops, and connector testing laboratories. This integrated manufacturing model helps ensure stable quality control and shorter lead times.

Strict Testing Standards

Every WF28 connector undergoes multiple inspections, including electrical conductivity testing, plugging lifespan testing, salt spray testing, waterproof testing, vibration resistance testing, and dimensional accuracy inspection.

OEM & ODM Capability

We support customized projects for industrial customers worldwide, including custom cable assemblies, connector logo branding, special pin configurations, waterproof structure optimization, and customized packaging solutions.

Applications

The WF28 Aviation Connector is widely used in industrial automation equipment, smart manufacturing systems, robotics and motion control, outdoor electrical devices, power distribution systems, communication equipment, testing and inspection instruments, and heavy-duty machinery and industrial control cabinets.

Selection Considerations for WF28 Connectors

When evaluating the WF28 Industrial Circular Power & Signal Plug for your project, consider the following decision points:

• Pin count and layout: Confirm the number of cores required (2/3/4/5/7/9/12 pin options) and whether you need mixed power and signal contacts in one housing.
• Mating configuration: Determine whether you need a cable plug, panel mount receptacle, or a combination, and verify the male/female orientation for your application.
• Termination method: Select between solder and crimp termination based on your assembly process and field maintenance requirements.
• Environmental exposure: Assess vibration levels, moisture, and temperature range to confirm the threaded locking and metal shell provide adequate protection.
• Electrical load: Verify that the contact diameter and rated current match your power circuit demands before specifying the connector.

Application Boundaries

The WF28 series is well suited for industrial power input, motor control wiring, and automation signal routing in factory environments. However, it is not intended for submersible applications, high-flex robotic cable management, or installations requiring tool-free quick disconnect. For those requirements, consider alternative connector families with appropriate sealing and locking characteristics.

Inquiry Checklist

To receive an accurate quotation and configuration recommendation, please provide the following information:

• Required pin count and contact arrangement
• Mating side requirement (plug, receptacle, or both)
• Cable outside diameter and conductor size
• Electrical load (current and voltage)
• Environmental conditions (temperature, moisture, vibration)
• Order quantity and target delivery timeline

Why Choose WF28 Connectors?

The WF28 Industrial Circular Power & Signal Plug combines rugged aviation-style durability, stable electrical performance, reliable environmental protection, flexible industrial integration, and factory-direct quality assurance. Backed by a manufacturer with 15+ years of connector production experience, the WF28 series provides a dependable solution for industrial connectivity applications where reliability matters most.

Contact Us

We provide sample support, technical consultation, OEM/ODM customization, fast production & delivery, and factory-direct pricing. For detailed specifications and configuration assistance, contact our engineering team with your project requirements.
