MS27467E13B35SB MIL-DTL-38999 Series III 22-Pin Marine Connector

MIL-DTL-38999 MS27467 Circular Connectors

MS27467E13B35SB MIL-DTL-38999 Series III 22-Pin Circular Connector for Gyrocompass Systems

The MS27467E13B35SB is a MIL-DTL-38999 Series III circular connector with 22 pins, engineered for marine and shipboard applications where reliability and durability are critical. This connector supports secure signal and low-current power transmission for gyrocompass systems, ship control systems, navigation equipment, and communication devices operating in harsh ocean conditions.

Construction and Materials for Marine Environments

The connector features an aluminum alloy housing with a corrosion-resistant finish, suitable for saltwater, high humidity, and vibration-prone environments. The PTFE insulator provides excellent dielectric strength and supports a temperature range of -55°C to +200°C, accommodating extreme marine operating conditions. Contacts are brass plated with gold for reliable conductivity and corrosion resistance.

Bayonet Quick-Lock Coupling and Environmental Protection

The bayonet quick-lock coupling enables fast, secure mating while resisting loosening under shock or vibration. With an IP67 waterproof rating, the connector maintains reliable operation in wet or exposed maritime areas. The compact shell size 13 design supports efficient signal and low-current power distribution in space-constrained installations.

Selection Considerations for Gyrocompass Integration

• Pin configuration: Confirm the 22-pin layout matches your gyrocompass system wiring diagram before ordering.
• Gender and mounting: Verify whether your application requires the plug (male) or receptacle (female) version and cable or panel mounting style.
• Mating compatibility: Ensure the mating connector follows the same MIL-DTL-38999 Series III interface and shell size 13 specification.
• Cable range: Confirm the cable diameter and wire gauge fit within the connector's termination range for your installation.

Suitable and Unsuitable Applications

This connector is suitable for gyrocompass systems, navigation electronics, ship control panels, and communication equipment on commercial and military vessels where IP67 protection and vibration resistance are required. It is not intended for high-current power distribution, subsea or underwater mating applications, or environments exceeding the -55°C to +200°C temperature range.

Quality Evidence and Validation

The MS27467E13B35SB is manufactured to MIL-DTL-38999 Series III standards, with PTFE insulation and gold-plated brass contacts selected for long-term reliability in marine service. For specific test data, mating cycle ratings, or salt-spray performance values, consult the Technical Specifications or contact our engineering team.

Inquiry Checklist for Ordering

To ensure correct matching, please provide the following when requesting a quotation:

• Complete part number and quantity required
• Mating connector part number or interface drawing
• Pinout or wiring diagram for your gyrocompass system
• Cable type, diameter, and wire gauge for termination
• Mounting style: cable, panel, or PCB
• Any special plating or finish requirements

For related MIL-DTL-38999 Series III options, review the MIL-DTL-38999 MS27467 Circular Connectors catalog. For alternative marine connector configurations, see the MS27505E17B35P 55-Pin MIL-DTL-38999 Series III Circular Connector.

Contact our sales team with your application details to confirm compatibility and lead time for the MS27467E13B35SB or alternative configurations.
