SD13/SP13 Durable Flange Connector

SP13 Flange Connector Technical Drawing: Key Dimensions and Material Data

This technical drawing provides the verified measurements, material composition, and specification data for the SP13 flange connector. Use this page as a reference when checking panel cutouts, evaluating environmental resistance, or preparing a connector specification for an IP68-rated application.

What the Drawing Confirms About the SP13 Flange Connector

The drawing is intended to support engineering review and procurement decisions. It documents the physical envelope of the connector rather than its electrical performance, so pair it with the product datasheet when you need rated current, voltage, or contact resistance values.

• Mounting interface: Flange-mounted design for panel installation, with the drawing showing the flange footprint and fixing hole positions.
• Material composition: The drawing lists the housing and contact materials used in the standard configuration.
• Dimensional data: Overall length, width, height, and mating-face measurements are presented for panel cutout planning.

How to Use the Dimensional Data in Your Design

Before you finalize a panel layout, confirm that the flange dimensions in this drawing match your enclosure wall thickness and available mounting space. The drawing shows the connector in its unmated state; allow additional clearance for the mating plug and cable bend radius in your assembly.

If your application requires a different mounting style or pin configuration, the SP13 series includes related flange connector variants that may better match your interface requirements.

Related SP13 Flange Connector Resources

For application examples and series-level comparison, review the following resources:

• SD13/SP13 Durable Flange Connector catalog overview
• SP13 6 Pin flange connector IP68 case study for outdoor LED displays

Next Step: Confirm Your Connector Specification

To verify that the SP13 flange connector matches your electrical and mechanical requirements, send the drawing number and your target pin count, rated current, and IP rating to our engineering team through the inquiry form. Include your panel thickness and mounting hole pattern so we can confirm fit before you order.
