LD24/SP24 Panel Mount Connector Overview

This drawing provides an in-depth look at the LD24/SP24 panel mount connector, showing all dimensions, specifications, and material characteristics. It is intended for engineers and procurement specialists who need to verify mechanical fit, electrical ratings, and environmental suitability before integrating this connector into a control cabinet, power distribution unit, or industrial machine.

Key Selection Criteria for the LD24/SP24 Series

When evaluating the LD24/SP24 panel mount connector for your application, focus on the following decision points:

• Mounting configuration: Confirm whether your design requires a panel mount socket or plug, and verify the panel cutout dimensions against the drawing.
• Contact arrangement: Check the pin count and layout to ensure it matches your mating cable assembly and wiring scheme.
• Electrical ratings: Verify the rated current and voltage against your load requirements, and account for any derating at elevated ambient temperatures.
• Environmental protection: Confirm the IP rating and operating temperature range relative to your installation environment, especially if the connector will be exposed to moisture or dust.
• Material compatibility: Review the housing and contact materials for corrosion resistance and suitability for your specific media or washdown conditions.

Understanding the Dimensional Drawing

The drawing provides critical mechanical data for panel preparation and connector installation. Pay particular attention to the panel cutout diameter, mounting hole spacing, and overall connector depth, as these determine whether the connector fits your enclosure or bulkhead. The drawing also specifies thread types and tightening torque where applicable, which are essential for achieving a reliable seal and stable mechanical connection.

Electrical and Environmental Parameters

Use the specification table in the drawing to confirm the connector's rated current, rated voltage, insulation resistance, and contact resistance. These values define the connector's safe operating envelope. The IP rating and temperature range indicate the level of protection against ingress and thermal stress, but note that the waterproof performance typically applies only when the connector is mated and properly locked.

Material and Construction Details

The drawing lists the housing material, contact plating, and sealing material. These details influence the connector's durability in demanding industrial environments. For example, a metal housing with corrosion-resistant plating is generally preferred for high-vibration or high-temperature applications, while a thermoplastic housing may be sufficient for indoor, low-stress installations.

Application Fit and Installation Notes

The LD24/SP24 panel mount connector is commonly used in battery production lines, charging equipment, and industrial automation systems where a secure, waterproof connection is required. Before installation, verify that the mating plug or cable assembly uses the same series and contact arrangement to ensure proper keying and electrical continuity. For applications involving frequent mating cycles, confirm the connector's rated mating durability against your expected service life.

For related technical data, review the LD24/SP24 docking connector specifications or the LD28/SP28 panel mount connector dimensions and materials to compare series options.

Next Step: Verify Your Application Requirements

Before placing an order, prepare the following information to confirm the correct configuration:

• Required pin count and contact layout
• Panel thickness and cutout dimensions
• Rated current and voltage for your load
• Environmental conditions (temperature, humidity, washdown exposure)
• Mating cable assembly type and termination method

If you have a specific application in mind, submit an inquiry with your electrical and mechanical requirements so we can confirm the correct LD24/SP24 variant for your project.
