Can industrial-grade connectors be used for medical surgical robots?

No. Medical surgical robots require medical-grade connectors, such as the Series HR25, not industrial-grade ones. The choice is driven by patient safety, biocompatibility, and sterilization requirements that standard industrial components do not meet.

Why medical-grade connectors are mandatory

Medical-grade connectors are specifically designed and certified for use in patient-care environments. They differ from industrial-grade connectors in several critical ways:

• Biocompatibility: They comply with the ISO 10993 standard, ensuring materials are non-cytotoxic and non-sensitizing when in contact with human tissue.
• Sterilization resistance: They withstand high-temperature sterilization at 121℃, compatible with hospital moist heat procedures.
• Disinfection compatibility: They resist wiping with alcohol, which is used for daily surface disinfection in clinical settings.
• Electrical safety: They feature a non-metallic, anti-conductive shell to avoid electric shock risks during surgery.

Risks of using industrial-grade connectors

Industrial-grade connectors are not designed for medical applications. They lack the required medical certifications and may release harmful substances over time, which could endanger patient safety. Their materials and construction are not validated for repeated sterilization cycles or biocompatibility.

Selection guidance for surgical robot connectors

When specifying connectors for medical surgical robots, verify the following before making a selection:

• Confirm the connector series is explicitly rated for medical use, not just industrial use.
• Check for ISO 10993 biocompatibility documentation and certification.
• Verify the connector's rated sterilization temperature and cycle count.
• Ensure the shell material is non-conductive and suitable for the surgical environment.
• Review the mating interface and pin count against your robot's specific requirements.

For further guidance on connector selection for robotic joints and end effectors, refer to our connector selection FAQ for industrial robots.
