PT01A-12-10PSR 10-Pin Circular Connector Overview

The PT01A-12-10PSR is a 10-pin circular connector engineered for reliable signal and control connections in industrial automation systems. Its aluminum alloy housing provides structural strength and corrosion resistance, while the IP67 rating protects against dust and temporary water immersion, supporting dependable operation in demanding factory environments.

Key Selection Considerations

• Pin Configuration: 10 contacts with a 1.0 mm contact diameter, suited for multi-signal control wiring.
• Electrical Ratings: Supports 5A rated current and 250V AC, appropriate for typical control circuits and sensor interfaces.
• Termination Flexibility: Compatible with both solder and crimp termination methods, allowing adaptation to different assembly workflows.
• Environmental Protection: IP67-rated sealing guards against dust ingress and water splashes, enhancing reliability in harsh conditions.

Application Scope and Boundaries

This connector is well-suited for industrial control panels, automation machinery, and electronic equipment requiring secure multi-pin connections. It is designed for applications within its rated electrical and environmental limits. It is not intended for high-current power distribution or submersion beyond IP67 test conditions. Verify compatibility with your mating connector and cable specifications before installation.

Installation and Mating Guidance

For proper mating, confirm the connector gender and pin arrangement against your mating part. Prepare cables according to the recommended conductor size and strip length for solder or crimp termination. Ensure the coupling mechanism is fully engaged to maintain the IP67 seal. For detailed dimensional and material data, refer to the Technical Specifications section.

Inquiry Checklist

To ensure accurate matching, please provide the following when inquiring:

• Mating connector part number and gender
• Pinout or wiring diagram requirements
• Cable outside diameter and conductor size
• Electrical load (current, voltage) and environment conditions
• Required order quantity

For related industrial connector options, explore the 12G Series Circular Connectors or review the LD20/SP20 Industrial Flange Connector Dimensions and Specs for alternative configurations.
