SD13/SP13 Panel Mount Connector Overview

This technical drawing provides a clear dimensional and specification reference for the SD13/SP13 panel mount connector series. It is intended for engineers and procurement professionals who need to verify mounting dimensions, shell size, and material details before integrating the connector into a control cabinet, machine interface, or industrial enclosure.

What This Drawing Covers

The drawing documents the physical envelope and key engineering data for the SD13/SP13 panel mount connector, including:

• Overall panel cut-out dimensions and mounting hole spacing
• Shell diameter and flange thickness for panel fit assessment
• Contact arrangement and pin count as shown in the front view
• Material specification for the shell and insulator
• Thread type and mating depth for plug engagement

How to Use This Drawing for Selection

Before ordering, verify the following points against your application requirements:

• Confirm the panel thickness range matches the flange design of the SD13/SP13 connector.
• Check that the cut-out diameter and mounting hole pattern align with your enclosure layout.
• Verify the mating plug series (SP13) is compatible with the panel mount receptacle (SD13) for your pin count.
• Review the environmental sealing provisions if the connector will be exposed to moisture or dust in service.

If your application requires a different pin count or panel mounting style, review the related panel mount connector specifications for comparison.

Next Step

Use the drawing dimensions to confirm fit in your design, then submit an inquiry with your required pin count, cable entry direction, and quantity. A KMYD engineer can confirm availability and lead time based on the drawing data.
