For fan coil control in building central air conditioning systems, the connector should be compatible with the Modbus protocol, a widely adopted standard in building automation. This ensures reliable communication between the fan coil unit and the central control system.

Recommended Connector Configuration

A simple DIN connector (4Pin) is recommended for this application. This configuration supports:

• 0~10V analog signals for controlling fan speed and valve opening
• RS485 digital signals for transmitting temperature and wind speed data
• Transmission distance up to 1000 meters, sufficient to cover buildings up to 100 stories

Environmental and Installation Considerations

The connector features an IP65 protection rating, which prevents condensation damage commonly associated with fan coil units. Its tool-free threaded locking design allows for quick installation by rotation, enabling building maintenance staff to replace connectors efficiently without specialized tools.

Selection Notes

When selecting a connector for fan coil control, verify that the chosen model supports the required signal type (analog or digital) and meets the environmental protection needs of your installation site. Confirm the transmission distance requirements based on your building layout and control system architecture.
