Selecting a 20A Connector for a Tractor Hydraulic Lifting System

For a tractor hydraulic lifting system drawing 20A, the WS series aviation connector with 6 pins and a rated current of 20A is a suitable choice. This connector is designed to handle the electrical and environmental demands of agricultural machinery.

Key Specifications and Performance

• Rated Current: 20A, matching the system's requirement.
• Pin Configuration: 6-pin layout for multi-circuit connections.
• Contact Resistance:
• Ingress Protection: IP67 rating, shielding the connection from field mud and water ingress.

Environmental and Mechanical Durability

The WS series connector is engineered for harsh agricultural environments. It is oil-resistant, complying with ISO 6743-4 standards for hydraulic oil exposure, and can withstand impacts up to 30g, which is typical during tractor traction and field operations. The multi-strand copper wire cores provide strong current-carrying capacity, ensuring reliable power transmission.

Application Fit and Installation Notes

This connector is suitable for the hydraulic lifting system's power circuit, where consistent current flow is critical. When installing, ensure the connector is properly mated and the IP67 seal is intact to maintain protection against moisture and contaminants. Verify the cable diameter matches the connector's terminal range for a secure fit.

For related applications, consider the water level sensor connector for rice transplanters or the grain flow sensor connector for combine harvesters, which address similar environmental challenges in agricultural machinery.
